BVA 5 Ton 0.24″ Stroke Flat Body Single Acting Cylinder HF0503

• BVA Hydraulics
• BVA 5 Ton 0.24 Stroke Flat Body Single Acting Cylinder HF0503
• Features:
• Full compliance under ANSI B30.1 Standard
• Made of high quality steel
• Extremely short collapsed height can be used with applications having almost no clearance at the lift point
• Maximum working pressure: 10;000psi/700 bar
• Cylinder Capacity (Tons): 5
• Stroke (in.): 0.24
• Model Number: HF0503
• Cylinder Effective Area In2): 1.10
• Pressure at Capacity: 9;090
• Oil Capacity (in3): 0.26
• Weight (lbs.): 1.3

“
