Diamond Products 14″ Core Cut 2.5HP Electric CC525MXL2-E1 Masonry Saw 03726

Diamond Products

CC525MXL2-E1 2.5HP Masonry Saw 03726

FEATURES:

• Stay level blade guard.
• Removable cutting head.
• Leg kit standard-folding stand optional.
• Side carrying handles.
• Replaceable conveyor cart rails.
• Includes water pump.
• Vulcanized rubber coated material slide cart.
• Open throat cutting.
• Easy and safe access to depth control lock.
• Open back cutting allows longer material to be cut.
• Heavy duty frame design help resist damage to saw body.
• Reinforced slide rails keep the cart running smoothly.
• Sealed drain hole on the bottom of the tray allows quick clean up.

SPECIFICATIONS:

Maximum Depth of Cut	5”
Blade Shaft Diameter	7/8”
Arbor Diameter	1”
Blade Shaft Bearings	Flange block ball bearings
Blade Shaft Drive	2 Belt
Blade Mounting	Right (electric); Left (gas)
Blade Raise/Lower	Counterbalanced; spring tensioned head pivots on two 7/8” flange block bearings.
Blade Coolant	Dual spray tubes; pump fed (electric models); pump from tray (gas models).
Air Filter	3-stage cyclone (gas models)
Fuel Capacity	1 gallon (gas models)
High Temp Shut-off	Included (electric models)
