Enerpac 49 ton Capacity, .63 in Stroke, General Purpose Hydraulic Cylinder RC50
$134.99
Enerpac
4.9 ton Capacity, .63 in Stroke, General Purpose Hydraulic Cylinder RC50
RC-Series Hydraulic Cylinders are incredibly durable and versatile. These single acting hydraulic cylinders are suitable for a wide range of applications; lifting, pushing, or pressing.
FEATURES:
- Bearing system with composite wear bands for optimal sideload resistance
- Strengthened stop ring improves durability and side load resistance
- Trio Hybrid pre-tensioned spring system provides faster retraction
- High-grade polyethylene seals for low wear and long service life
SPECIFICATIONS:
| Maximum Operating Pressure (psi) | 10,000 |
| Maximum Cylinder Capacity Advance (short tons) | 4.9 |
| Stroke (in) | 0.63 |
INCLUDES:
(1) Hydraulic Cylinder
| Base Mounting Holes Thread V | 5,6 mm | 0.22 in |
|---|---|
| Collar Thread Length X | – in | ‘- mm |
| Return Type | Single-Acting, Spring Return |
| Outside Diameter D | 2.31 in | 58 mm |
| Dimension D1 | 41 mm |
| Collapsed Height A Ranges | 0 – 4.99 in | 0 – 127 mm |
| Base Mounting Holes Thread Depth Z | – in | ‘- mm |
| Features | Mounting Options |
| Cylinder Capacity Tons Maximum | 4.9 |
| Product Line | Industrial Tools |
| Oil Capacity Advance | 0.62 in³ | 10 cm³ |
| Baseto Advance Port H | 0.75 in | 19 mm |
| Cylinder Material | Steel |
| Dimension M | 25 mm |
| Cylinder Effective Area Advance | 0.99 in² | 6,4 cm² |
| Cylinder Bore Diameter | 1.13 in |
| Extended Height | 2.25 in |
| Type | Hydraulic Cylinders |
| Dimension L | 20 mm |
| Oil Capacity | 0.62 in³ |
| Plunger Diameter | 1 in |
| Maximum Operating Pressure Ranges psi | 10000 |
| Upsell item | RC51,RR506 |
| Sub Types | General Purpose Cylinder |
| Plunger internal Thread O | ‘- in |
| Surface Treatment | Paint |
| Plunger internal Threadin O | ‘- in |
| Base To Advance Port | 0.75 in |
| Plunger Type | Solid |
| Weight | 2.2 lbs | 1,0 kgs |
| Saddle Protrusion From Plunger K | ‘- mm |
| Base Mounting Hole Bolt Circle | 1.13 in |
| Plunger Diameter F | 1 in | 25,4 mm |
| Collapsed Height A | 1.63 in | 41 mm |
| News Feed Product Group | Cylinders and Jacks |
| Shipping Weight | 2.25 lbs |
| Maximum Cylinder Capacity Advance | 4.9 Imperial Tons | 45 kN |
| Cylinder Effective Area | 0.99 in |
| Extended Height B | 2.25 in | 57 mm |
| Cylinder Class | 5 Imperial Tons |
| Collar Thread W | – in | ‘- mm |
| Country of Origin | China |
| Outside Diameter | 2.31 in |
| Plunger Thread Length P | ‘- mm |
| Base Mounting Hole Thread | 0.22 in |
| Cylinder Bore Diameter E | 1.13 in | 28,6 mm |
| Base Mounting Holes Bolt Circle U | 1.13 in | 29 mm |
| Stroke Ranges | 0 – 0.99 in | 0 – 23 mm |
| Saddle Diameter J | ‘- mm |
| OPT SKU | ENP-RC50 |
|---|---|
| MPN | RC50 |
| UPC/GTIN | 662005300549 |
| Product Type | Cylinder Rams Single Acting |
| Google Category | Business & Industrial > Material Handling |
| Stroke | 1″ |
| Tonnage | 5-Ton |
| Shipping Weight | 3.00 |
