Honda WT20X 2″ Trash Pump GX160 185 gal/min Dewatering WT20XK4AC

Honda

Honda WT20X Trash Pump WT20XK4AC

FEATURES:

• Heavy-duty 2 construction trash pump.
• Easy starting Honda OHV commercial engine.
• 185 gal./min capacity.
• Solid handling capability up to 13/16″.
• Cast iron volute and impeller.
• Quick clean out port.

SPECIFICATIONS:

Engine	GX160
Displacement	163 cc
Bore and stroke	2.7″ x 1.8″
Compression Ratio	9.0:1
Oil Alert	Std
Pump type	Trash Centrifugal Self-priming
Volute	Rigid Mounted Cast Iron w/ Stainless Wear Plate
Impeller	Conical Cast Iron
Mechanical Seal (Pump case / impeller)	Silicon Carbide/Silicon Carbide
Priming time	60 sec. @ 16.4 ft.
Drive system	Direct
Discharge capacity	185 gal/min
Suction port diameter	2″
Discharge port diameter	2″
Total head lift	85 ft.
Suction head lift	26 ft.
Maximum pressure	37 psi
Solids handling	13/16 inches
Dimensions (LxWxH)	24.4″ x 18.1″ x 18.3″
Dry weight	104 lbs.
Fuel Capacity	0.82 gal
Run Time @ Max Discharge	1.5 hr
Residential Warranty	3 years
Commercial Warranty	3 years

“
