Klein Chicago Grip Coated Guy Wire w/ Chain 16845CAT

Klein

Chicago Grip Coated Guy Wire w/ Chain 16845CAT

This Chicago Grip is designed specifically to work with coated guy strand and EHS cable. Klein grips are made of drop-forged; quality US steel and heat treated for strength and durability.

FEATURES:

• Aggressive sawtooth jaw profile resists build-up from galvanized coating on guy strand and EHS cables.
• Equipped with chain; toggle and shackle to keep grip from falling off the cable.
• Locking handle keeps jaw open while grip is placed on cable with a hot stick.
• Spring closes grip on cable helping to maintain initial position.
• Designed for cable sizes 0.218 to 0.55-Inch (5.54 to 13.97 mm).

SPECIFICATIONS:

Type	Chicago Grip
Hot Latch	No
Swing Latch	No
Spring	Yes
Locking Handle	Yes
Length	13.3
Height	2.5″
Width	7.6″
Material	Alloy Steel
Cable Type	Aircraft; EHS; Messenger; Guy Strand
Cable Diameter	0.218″ to 0.55″
Jaw Type	Aggressive
Jaw Length	5″
Maximum Safe Load	8000 lb

*WARNINGS:*

• Before each use; clean jaw area and inspect grip for proper operation to avoid slippage.
• When used on/near energized lines; ground; insulate; or isolate grip before pulling.
• Do not exceed rated capacity.
• Always match proper size and type of grip to application.
• Grips are to be used for temporary installation; not for permanent anchorage.

“
