Power Team 10 Ton Hydraulic 6″ Threaded Base Spring Return Cylinder C106CBT

• Power Team
• THREADED PISTON ROD END AND BASE THREADS ACCOMMODATE ACCESSORIES AND ADAPTERS.
• Threaded cylinder collars; piston rod ends; and internal base threads simplify mounting.
• A 9796 3/8″ NPTF female half coupler is standard with each cylinder; oil port threads are 3/8″ NPTF.
• Order No.  : C106CBT
• Cyl. Cap. (tons) : 10
• Stroke (in.)  : 6 1/8
• Oil Cap. (cu. in.) : 13.9
• Bore Dia. (in.) : 1 11/16
• Cyl. Eff. Area (sq. in.): 2.236
• Internal Press at Cap. (psi): 8;948
• Tons at 10000 (psi) : 11.2
• Weight (lbs.)  : 10.3
• Re- tracted Height (in.): 11 1/2
• Ex- tended Height (in.): 17 5/8
• Outside Dia. (in.) : 2 1/4
• Collar Thread (in.) : 2 1/414
• Collar Thread Length (in.): 1 1/8
• Base to Port (in.): 1 11/16
• Piston Rod Dia. (in.): 1 1/2
• Piston Rod Protrusion (in.): 1  1/16
• Piston Rod Thread (NPT): 1 1/411 1/2
• Internal Base Thread (NPSM) (in.): 1 1/411 1/2

“
