Power Team 17.5 ton hydraulic 2 single acting cylinder center hole RT172
Center hole cylinder ideal for pulling and pressing applications
FEATURES:
- Basic head can be changed from a tapped hole to plain hole by simply changing insert
- 12; 20; 30; 50; 60 Ton Single-Acting Models Feature Threaded Collar; Model RH203 and RHA306 do not feature the collar thread
- Withstands full “dead-end” loads
- Corrosion resistant standpipe has “Power Tech” treatment
- All cylinders except RH120 are furnished with a 9796 3/8″ NPT female half coupler
- Aluminum cylinder body and piston are featured on the RHA306 cylinder
SPECIFICATIONS:
| Stroke length: | 2.000″ |
|---|---|
| Piston rod diameter: | 1.750″ |
| Series/type: | RT-Series/Center hole |
| Actuation/return: | Single acting/Spring return |
| Cylinder capacity: | 17.5 Ton |
| Oil capacity: | 7.060″³ |
| Retracted height: | 6.875″ |
| Extended height: | 8.875″ |
| Effective area: | 3.530″² |
| Tons at 10;000 PSI: | 17.70 Ton |
| Max pressure: | 10;000 PSI |
| Bore size: | 2.120″ |
| Outside diameter: | 2.750″ |
| Center hole diameter: | 1.031″ |
| Load cap thread: | 1-8 |
| Load cap diameter: | 1.750″ |
| Material: | Steel |
| Weight: | 14.60lbs |
“
| OPT SKU | PTRT172 |
|---|---|
| MPN | RT172 |
| UPC/GTIN | 662536003612 |
| Product Type | Cylinder Rams Single Acting |
| Google Category | Business & Industrial > Material Handling |
| Stroke | 2″ |
| Tonnage | 17-1/2-Ton |
| Shipping Weight | 15.00 |
