Power Team 50 Ton Hydraulic 3″ Dual Single Acting Cylinders Center Hole RT503

Power Team

50 Ton Hydraulic 3 Dual Single Acting Cylinders Center Hole RT503

FEATURES:

• Power Team
• IDEAL FOR PULLING AND PRESSING.
• A proven design; used throughout industry for over 45 years.
• Cylinders withstand full dead-end loads.
• Compact design; ideal for applications in which space is limited.
• Basic head can be changed from a tapped hole to plain hole by simply changing insert.
• Pistons have Power Tech treatment for corrosion and abrasion resistance.
• Order No.   : RT503
• Cyl. Capacity (tons) Push: 50
• Stroke (in.)  : 3
• Oil Cap. (cu. in.)  Push: 29.4
• Oil Cap. (cu. in.)  Return:
• Mounting Hole (in.) : 21/32
• Cyl. Eff. Area (sq. in.) : 9.81
• Int. Press at Cap. (psi) : 10;193
• Tons at 10;000 (psi)  : 49.1
• Weight (lbs.)  : 56
• Retracted Height (in.) : 10  9/16
• Extended Height (in.) : 13  9/16
• Outside Dia. (in.) : 5 7/8
• Outside Dia. (in.) : 9 3/8
• Load Cap Dia. (in.) : 2 7/8
• Load Cap Dia. (in.) : 1 5/8″5 1/2
• Center Hole Dia. (in.): 1 43/64
• Mounting Hole Location (in.): 2 3/8

“
