Power Team 55 Ton Hydraulic 10″ Single Acting Cylinder Spring Return C5510C

• Power Team
• RUGGED; HIGH QUALITY CYLINDER USED FOR LIFTING AND PRESSING
• Aluminum bronze bearing reduces wear caused by off-center loads.
• Maximum sized springs speed piston return and increase spring life.
• Solid steel cylinder body for durability.
• Chrome plated piston rod resists wear and corrosion.
• Wide range of accessories available to thread onto piston rod; collar; or onto cylinder base.
• Base mounting holes standard on 5 through 55 ton cylinders; optional on 75 and 100 ton cylinders.
• A 3/8 NPTF female half coupler is standard.
• Order No.: C5510C
• Cylinder Capacity (Tons): 55
• Stroke (in.): 10 1/4
• Oil Cap. (cu. In.): 113.2
• Bore Diameter (in.): 3 3/4
• Cylinder Effective Area (sq. in): 11.04
• Internal Pressure at Cap. (psi): 9959
• Tons at 10;000 psi (psi): 55.2
• Weight (lbs.): 67
• Retracted Height (in.): 15 1/8
• Extended Height (in.): 25 3/8
• Outiside Diameter (in.): 5
• Collar Thread (in.): 42136
• Piston Collar Thread Length (in.): 2 1/5
• Base to Port (in.): 1 3/8
• Piston Rod Diameter (in.): 3 1/8
• Piston Internal Thread and Depth (in.): None
• Rod Protrusion (in.):  1/8

“
