- (2) Steel Extension Wings
- (1) Miter Gauge
- (1) Micro Blade Guard
- (1) Riving Knife
- (2) Blade Wrenches
- (1) Push Stick
- (1) 10″ Blade
- (1) Standard Lockdown Insert
- (1) Standard Brake Cartridge
- (1) Owner’s Manual
- (1) Assembly Instructions
- (2) Hardware Packs
- (1) 3mm Hex Key
- (1) 5mm Hex Key
- (1) 8mm hex Key
- 52″ Professional T-Glide Fence System provides smooth operation, an expansive work surface, precision measurement and sure lockdown without deflection.
- SawStop Safety System stops on contact with skin.
- Includes Two Steel Extension Wings
- The most configurable saw in the SawStop lineup
- Dimension: 85 1/4 ” w, 45″ d, 34 3/4″ h
- Precision, performance and safety all come together to make this the right choice for experts looking for a reliable saw at an affordable price.
- Two year warranty with saw registration.
| 52 Rip Capacity | 52″ T-Glide Fence Assembly | |
|---|---|---|
| Motor Option(s) (60Hz TEFC) | 1.75 HP available | |
| Overall saw dimensions 52 in | 85 1/4″ W x 45″ D x 34 3/4″ H | |
| Motor Configuration(s) | CNS175 | 1.75 HP, 120v, 14 A (user config. to 220v w/optional kit available for purchase) |
| Saw body footprint | 25 3/4″ W x 27″ D (w/stand installed) | |
| Cast iron table | 20″ W x 27″ D | |
| Cast iron table (w/ extension wings) | 44″ W x 27″ D | |
| Extension wings | 12″ W x 27″ D Stamped Steel (optional cast iron for purchase) | |
| Extension table 52 in | 40 1/8″ W x 27″ D | |
| Shipping weights – w/ 52 in fence systems | 373 lbs (4 boxes) | |
| Shipping dimensions (saw body only) | 35″ W x 30″ D x 20″ H | |
| Shipping weight (approx.) | 240 lbs (table saw only) | |
| Assembled weights – w/ 52 in fence systems | 335 lbs | |
| Weights – table saw only | 225 lbs | |
| Weights – (optional cast iron wings) | 35 lbs each | |
| Blade | 40-tooth, prof. grade, 5/8″ arbor | |
| Blade diameter | 10″ | |
| Blade tilt | Left | |
| Blade kerf | 0.118″ (3mm) | |
| Blade plate thickness | 0.078″ (2mm) |
| OPT SKU | KIT-SAWCNS175-TGP252 |
|---|---|
| MPN | CNS175-TGP252 |
| Product Type | Table Saws |
| Google Category | Hardware > Tools > Saws > Table Saws |
| Diameter | 10″ |
| Power Method | Corded/Electric |
| Package | Bundle |
| Voltage | 110V/120V |
| Shipping Weight | 370.00 |
