- Simplex
- RLS502 – Cylinder
- HD internal spring for retract assistance.
- Heat treated hardened load cap is standard.
- Stop ring for piston blow-out protection.
- Plated piston to resist scoring & corrosion.
- High flow couplers are plated to resist corrosion.
- Rod wiper protects inner cylinder from dirt.
- Model # : RLS502
- Name : Cylinder
- Order # : RLS502
- Capacity : 50 ton
- Stroke : 2.38 inch
- Min. Height : 4.81 inch
- Max. Pressure : 10000 psi
- Oil Cap. Req. : 22.8 cu. in.
- Weight : 24 lbs.
| OPT SKU | SIMRLS502 |
|---|---|
| MPN | RLS502 |
| UPC/GTIN | 812761020919 |
| Product Type | Cylinder Rams Single Acting |
| Google Category | Business & Industrial > Material Handling |
| Stroke | 2-1/2″ |
| Tonnage | 50-Ton |
| Shipping Weight | 30.00 |
